We use Telepresence in our Kubernetes development stack at Coder Society. Telepresence lets you connect a process running locally on your laptop to a Kubernetes cluster. This is useful for development as well as debugging purposes since it gives you access to the running Kubernetes services without having to expose them publicly.
You can find the code which we use in this article on GitHub: https://github.com/coder-society/kubernetes-with-telepresence
We assume that you already have a running Kubernetes cluster and kubectl installed.
On OS X you can install Telepresence with Homebrew:
$ brew cask install osxfuse
$ brew install datawire/blackbird/telepresence
You can find installation instructions for other platforms here.
Verify that your Kubernetes cluster is running:
$ kubectl get nodes
NAME STATUS AGE VERSION
ip-172-20-113-130.eu-central-1.compute.internal Ready 14m v1.7.0
ip-172-20-119-81.eu-central-1.compute.internal Ready 16m v1.7.0
ip-172-20-46-215.eu-central-1.compute.internal Ready 14m v1.7.0
ip-172-20-56-176.eu-central-1.compute.internal Ready 16m v1.7.0
ip-172-20-66-175.eu-central-1.compute.internal Ready 14m v1.7.0
ip-172-20-76-235.eu-central-1.compute.internal Ready 16m v1.7.0
Run curl ifconfig.co to get your public IP address:
$ curl ifconfig.co
37.209.72.147
Start a shell that proxies network traffic to Kubernetes and verify that the IP address differs from your public IP address:
$ telepresence --run-shell
$ curl ifconfig.co
52.29.24.213
We prepared a simple echo-server which you can deploy to your Kubernetes cluster:
$ kubectl apply -f [./echo-server/echo-server.yaml](https://github.com/coder-society/kubernetes-with-telepresence/blob/master/echo-server/echo-server.yaml)
Verify that the pods are running:
$ kubectl get pods
NAME READY STATUS RESTARTS AGE
echo-server-1203620631-mk089 1/1 Running 0 6s
echo-server-1203620631-pv53n 1/1 Running 0 6s
echo-server-1203620631-r035z 1/1 Running 0 6s
The echo-server is accessible through a Kubernetes service which is not publicly exposed. You can use Telepresence to make a request to the service name. Execute the curl command with the --run option:
$ telepresence --run curl http://echo-server
{"status":"ok","time":1502747082460,"hostname":"echo-server-1203620631-r035z"}
We created a simple task-runner which makes every 3 seconds a request to the echo-server. You can start the local node process with the Telepresence — run option:
$ telepresence --run node [task-runner/index.js](https://github.com/coder-society/kubernetes-with-telepresence/blob/master/task-runner/index.js)
{"status":"ok","time":1502747926293,"hostname":"echo-server-1203620631-r035z"}
{"status":"ok","time":1502747929273,"hostname":"echo-server-1203620631-pv53n"}
{"status":"ok","time":1502747932260,"hostname":"echo-server-1203620631-mk089"}
Deploy the echo-server and task-runner to the Kubernetes cluster:
$ kubectl apply -f [./echo-server/echo-server.yaml](https://github.com/coder-society/kubernetes-with-telepresence/blob/master/echo-server/echo-server.yaml)
$ kubectl apply -f [./task-runner/task-runner.yaml](https://github.com/coder-society/kubernetes-with-telepresence/blob/master/task-runner/task-runner.yaml)
Verify that the pods are running:
$ kubectl get pods
NAME READY STATUS RESTARTS AGE
echo-server-1203620631-mk089 1/1 Running 0 49m
echo-server-1203620631-pv53n 1/1 Running 0 49m
echo-server-1203620631-r035z 1/1 Running 0 49m
task-runner-297154768-1btr3 1/1 Running 0 40m
Swap out the echo-server deployment and start the local node server which is exposed on port 3000:
$ telepresence --swap-deployment echo-server --expose 3000 --run node [echo-server/server.js](https://github.com/coder-society/kubernetes-with-telepresence/blob/master/echo-server/server.js)
Echo Server listening on [http://localhost:3000](http://localhost:3000)
Incoming request: 1502666001958
Incoming request: 1502666004957
Incoming request: 1502666007957
The server will now receive the traffic from the task-runner pod which is running inside the Kubernetes cluster.
Telepresence is an invaluable tool for developing and debugging applications running on Kubernetes. Its functionality to provide secure access to Kubernetes services can also be useful in other situations such as when running integration tests for your private Kubernetes services.
